24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed

Certification
China ASLT(Zhangzhou) Machinery Technology Co., Ltd. certification
China ASLT(Zhangzhou) Machinery Technology Co., Ltd. certification
I'm Online Chat Now

24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed

24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed
large.img.alt
24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed 24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed 24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed

Large Image :  24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed

Product Details:
Place of Origin: China
Brand Name: Bodsee
Model Number: CNC-1250GM
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: Negotiation
Packaging Details: Wooden Package
Delivery Time: Negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 30set/month

24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed

Description
X Axis Travel: 1200mm Y Axis Travel: 500mm
Z Axis Travel: 500mm Cutting Rapid Feed: 8000mm/min
Work Table Size: 1800x420mm Tool Changer: Carousel Tool Changer
Tool Capacity: 12/24pieces Dimension Of Machine Tool: 2250*1700*2300mm
High Light:

CNC Milling Machine XYZ Axis

,

8000mm/Min Milling Machine XYZ Axis

Long Work Table 1800x420mm 24pcs Tool Capacity Axis CNC Milling Machine



Product Features:

1. The X/Y/Z axis adopts the linear guide-way structure, and the three-way line rail adopts the heavy pre-pressing process. So that the machine tool not only has the characteristics of high speed and high precision, but also has the characteristics of heavy cutting, excellent rigidity and excellent production efficiency.

2. Assembly main joint surface are hand scraping to ensure the effective contact of the joint surfaces.

3. The spindle motor and pulley are tested by the dynamic balancing instrument to ensure smooth operation.

4. The machine bed, column, saddle, worktable, main spindle box and other main basic parts are made of high quality cast iron. It adopts special casting process to improve the mechanical properties of materials. After annealing treatment and vibration aging, remove stress to ensure good rigidity and damping characteristic when the machine tool is used for cutting. At the same time, it has good thermal stability and stabilization precision.



Product Specification:

Model No. CNC-1250GM
X axis travel 1200mm
Y axis travel 500mm
Z axis travel 500mm
Distance from spindle nose to the work table 120-620mm
Distance from spindle center to column guideway 580mm
X rapid feed 36m/min
Y rapid feed 36m/min
Z rapid feed 24m/min
Cutting rapid feed 8000mm/min
The width of the triaxial linear guide 35mm
The number of the slider in the X axis 6 pieces
The number of the slider in the Y axis 4 pieces
The number of the slider in the Z axis 4 pieces
Triaxial screw size 40/12mm
Work table size 1800x420mm
The maximum load capacity 400KG
Table "T" type groove The number of grooves 4pieces
Width 18mm
Spacing 90mm
Positioning accuracy 0.01mm
Repeat positioning accuracy 0.008mm
Spindle speed range 20-8000rpm/min
Feed axis motor power 1.8/1.8/2.5KW
Feed motor connection form Direct Connection
Taper of spindle hole BT40
The spindle of output power 5.5/7.5KW
Cooling box form Independent
Tool Changer Carousel tool changer
Tool Capacity 12/24pieces
Dimension of machine tool 2250*1700*2300mm
Weight of machine 2450KG



24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed 0



Product Description:

CNC-1250GM vertical maching center machine is a numerical control machine with superior cost performance and equipped with a numerical control system. It can realize hole-machining operations such as drilling, counterboring, reaming,Boring, and tapping processing for various complex parts such as discs, plates, shells, cams, molds, etc.. It is suitable for processing parts with high accuracy and productivity requirements and reduces labor intensity. The machine is suitable for automobile, motorcycle, aerospace, military, instrument, meter, electronics, mold and other industries.





Our Company:

ASLT(Zhangzhou) Machinery Technology Co., Ltd. is located in Zhangzhou, Fujian, China. Our company is a Scientific and Technological Enterprises specializing in CNC machine research and development, manufacturing and sales. With over 20 years of CNC machine manufacturing experience, ASLT has accumulated strong technical force and has many professional and technical personnel.

24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed 1

24 Pcs Tool Capacity CNC Milling Machine XYZ Axis 8000mm/min Cutting rapid feed 2







FAQ:

Q1. How can I choose the most suitable machines?
A: Please tell us your requirement of the machine, or you can also send us the products drawing, our engineer can help to choose the best model for you.
Q2. What's the main products of your company?
A: We specialized in many kinds of CNC machines, Vertical VMC Milling Machine.
Q3. Where is the factory located? How can I visit there?
A: Our factory is located in Zhangzhou City, Fujian Province, China. With very convenient transportation access.
Q4. What's the MOQ?
A: MOQ is 1 set.

Q5: What is your lead time?

A: It depends on customers’ requirement and quantity.
