High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail

High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail
High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail

Large Image :  High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail

Product Details:
Place of Origin: China
Brand Name: Bodsee
Model Number: CNC-M4S
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wooden Package
Delivery Time: Negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 30Set/Month

High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail

Description
Distance From Spindle Nose To The Work Table: 120+360 Mm Distance From Spindle Center To Column Guideway: 370 Mm
X Axis Travel: 830mm Y Axis Travel: 340(360)mm
Z Axis Travel: 360+120 Mm Cutting Rapid Feed: 1~4000mm/min
Work Table Size: 1370*280mm The Maximum Load Capacity: 350KG
Spindle Speed Range: 80-4500r/min
High Light:

High Rigidity VMC Vertical Machining Center

,

Hard Rail VMC Vertical Machining Center

High Rigidity 830mm x Axis Heavy Cutting Hard Rail VMC Vertical Machining Center



Product Features:



1. X. Y and Z guide rails are heavy duty pathway with high rigidity and low noise. They cooperate with automatic lubricative system to improve the precision life of machine tools;

2. X. Y. Z axis feed adopt high-precision grinding ball screw and the feeding speed is stable.

3. Adopt the Taiwan spindle with high precision and rigidity, with high radial and axial load capacity, and the maximum speed can reach 4500rpm.

4. The machine external protection of the machine tool adopts semi-protective structure design, which is easy to operate, safe and reliable.





Product Specification:



Model No. CNC-M4S
X axis travel 830mm
Y axis travel 340(360)mm
Z axis travel 360+120 mm
Distance from spindle nose to the work table 120+360mm
Distance from spindle center to column guideway 370mm
X rapid feed 8 m/min
Y rapid feed 8 m/min
Z rapid feed 6 m/min
Cutting rapid feed 1~4000mm/min
Triaxial screw size X 3208
Y 3208
Z 2505
Work table size 1370*280mm
The maximum load capacity 350KG
Table "T" type groove The number of grooves 3pieces
Width 16.5mm
Spacing 63.5mm
Positioning accuracy 0.025/300mm
Repeat positioning accuracy 0.015mm
Spindle speed range 80-4500r/min
Spindle Motor Power(kW) 3kw
Spindle Diameter Φ85.725mm
Cooling Motor 0.15kw
Triaxial Feed Motor Torque 6/6/4Nm
Taper of spindle hole R8(NT30)
Power Form (Voltage) Customized
Electric Capacity 7KVA
Water tank capacity 40L
Cooling box form Integrated
Dimension of machine tool 1500/1820/2380mm
Weight of machine 1700kg



High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail 0





Product description:

The product is a vertical CNC milling machine with X, Y and Z axis servo control.

The rectangular guideway has large load, high rigidity and compacted in design. The main shaft is 3KW motor driven by belt, it can complete drilling, milling, boring, reaming and other processes for various complex parts such as discs, plates, shells, cams and molds etc.. It is suitable for the production of multiple varieties, small and medium-sized batch of products, and can meet the processing of complex, high-precision parts in batches. It also can be equipped with the 4th rotating axis to meet the processing requirements of special parts.



Our Company:

ASLT(Zhangzhou) Machinery Technology Co., Ltd. is located in Zhangzhou, Fujian, China. Our company is a Scientific and Technological Enterprises specializing in CNC machine research and development, manufacturing and sales. With over 20 years of CNC machine manufacturing experience, ASLT has accumulated strong technical force and has many professional and technical personnel.

High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail 1

High Rigidity VMC Vertical Machining Center 830mm X Axis Heavy Cutting Hard Rail 2





FAQ:

1.How to send my enquiry?
You can contact us by email, phone call, Instant Messenger (WhatsApp, WeChat, Skype).
2. What's the main products of your company?
We specialized in many kinds of CNC machines, Vertical VMC Milling Machine.
3. Are you a manufacturer or a trader?
we are the manufacturer for CNC Vertical Milling Machines.
4. Lowest price?
We are the factory, we directly providing the lowest price with ensured after sale service.
